Description
Unpowered transmission systems offer a simple, efficient, and cost-effective way to move goods using passive rollers. Powered by either gravity or light manual effort, these systems can be installed in horizontal or inclined layouts, making them ideal for smooth, low-maintenance material flow across various industries.
| Sr. No. | Specification Parameter | Details |
| 1 | Roller Length | 300 mm to 1500 mm (custom sizes available) |
| 2 | Roller Diameter | Ø 38 mm, Ø 50 mm, Ø 60 mm, Ø 76 mm |
| 3 | Roller Material | MS (Mild Steel), SS (Stainless Steel – SS 304 / SS 316) |
| 4 | Shaft Material & Size | MS / SS shafts, Ø 12 mm, Ø 15 mm, Ø 20 mm |
| 5 | Surface Finish | MS: Painted / Powder Coated / Zinc PlatedSS: Natural / Mirror / Matte Finish |
| 6 | Load Capacity | Light Duty to Heavy Duty (depends on diameter & shaft size) |
| 7 | Mounting Options | Spring Loaded Shaft, Threaded Shaft, Plain Shaft with Circlip |
